Astra
Evolution
Evolution
Robust wireless solution with advanced networking functionality
Reliable solution for demanding tasks
The family of solutions guarantees many years of uninterrupted operation, thanks to its completely sealed enclosure, which is resistant to moisture and salt damage. All Astra Evolution products also come equipped with an advanced lightning protection.
Integrated router for complicated network scenarios
Astra Evolution has a built-in router functionality, eliminating the cost of installing an additional SOHO router at the customer’s premises. Potential cyber-security issues can be quickly addressed with a built-in firewall.
Versatile model range of subscriber terminals
The subscriber units provided with this product family are dual band, able to operate in both the 5 GHz and 6 GHz frequency bands. They can be fitted with a range of integrated and external antennas to cater for both short distances as well as longer ones of 25 km and further.
Astra Evolution
Base Station
Sectors
Base Station
Sectors
E5-BSQ
High-capacity base station sector with an integrated beamforming antenna
- Frequency Range: 4.9 – 6.05 GHz
- 21 dBi dual-pol integrated sector beamforming antenna 90°x8° (20° Az-steerable beam)
E5-BSI
High-capacity 5 GHz base station sector with an integrated antenna
- Frequency Range: 4.9 – 6.05 GHz
- 16 dBi dual-pol integrated sector antenna 90°x8°
E6-BSI
High-capacity 6 GHz base station sector with an integrated antenna
- Frequency Range: 6.05 – 6.425 GHz
- 16 dBi dual-pol integrated sector antenna 90°x8°
E5-BSE
High-capacity 5 GHz base station sector for an external antenna
- Frequency Range: 4.9 – 6.05 GHz
- High-capacity base station sector for an external antenna
E6-BSE
High-capacity 6 GHz base station sector for an external antenna
- Frequency Range: 6.05 – 6.425 GHz
- High-capacity base station sector for an external antenna
5+6 GHz
Subscriber
Terminals
Subscriber
Terminals
- Frequency Range: 4.9 – 6.425 GHz
- Up to 670 Mbps net throughput
E6-ST18
Short range integrated antenna subscriber terminal unit
- 18 dBi dual-pol integrated antenna 18×18 deg
E6-ST25
Medium range integrated antenna subscriber terminal unit
- 25 dBi dual-pol integrated antenna 8×8 deg
E6-ST28
Long range integrated antenna subscriber terminal unit
- 28 dBi dual-pol integrated antenna 5×5 deg
E6-STE
External antenna subscriber terminal unit
- Connectorized antenna (2 x N‑type connectors)
